功率穩定、可調節
電源自帶過熱、限流保護電路
可外接高速調制
適用于科研、激光測量、舞臺激光表演等
| 波長Wavelength (nm) | 589 | 功率穩定性Power Stability (RMS, over 8 hours) | <5% | |||
| 輸出功率 Output Power (mW) | 1 | 出光孔高度 Aperture Position (mm) | 45 | |||
| 工作方式 Working Mode | CW | 激光器Laser Head | 尺寸 Dimensions (L×W×H, mm) | 205 x 60 x 60 | ||
| 光斑模式Beam Mode | 橫模 Transverse | TEM00 | 可配電源型號 Integrated Driver Model | VD-II Series | ||
| 線寬Spectral Linewidth (nm) | <0.1 | 電源調制External Modulation | 5V TTL / 5V Analogue | |||
| 偏振方式 Polarization | Line polarization | 調制速率Modulating Repetition | 30KHz TTL / 10KHz Analogue | |||
| 偏振比Polarization Ratio | >100:1 | 制冷方式Cooling System | TEC+Air-cooled | |||
| 光束質量Beam Quality (M2 factor) | <1.5 | 預熱時間Warm-up Time (minutes) | <15 | |||
| 光束發散角Beam Divergence (full angle, mrad) | 1.2±0.2 | 工作溫度Operation Temperature (℃) | 18~30 | |||
| 光束直徑Beam Diameter at Aperture (mm) | 1.5±0.2 | 使用壽命Expected Lifetime (hours) | >10000 | |||
| 光束橢圓度 Beam Roundness | >90% | |||||
